Seamless Full Color LED Panel Stage Background LED Display Big Screen Hire 16 Bit
Seamless LED Video Wall is especially suitable for rental use. It's very lightweight and thin. Easy to assemble and dis-assemble. One person is able to hold a cabinet with one hand easily.
>> Function and Technology characters
1. Show all kinds of word, text, graph, pictures, flashes, video,2-dimension, 3-dimension cartoon and any other formats with your PC does synchronously.
2. Different signal resources input are acceptable, such as TV, HCTV, S-video, NTSC/PAL,DVI, AVI, VGA, SDI, MOV, MPG, etc. We have three display modes as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
3. 10 BIT grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chromic can be adjusted by manual and sensor, whose scope is 256 grade
4. Line-Double technology is adopted for the picture adjustment.
5. Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.
6. It can be used in advertisement, stage, stadium, exhibition, TV-Show,mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc
>> Product Description
| Item | Specification |
| Pixel | Physical pixel pitch: 6 mm |
| Pixel configuration: 1R1PG1PB |
| Module | Module resolution: 48 x 48pixel | Module size: 288 x 288mm |
| Cabinet | Cabinet resolution:96x96pixel | Cabinet size:576 x 576x60mm |
| Cabinet :9216pixels | Module Qty:4pcs=2(W)x2(H) |
| Material: Aluminum | Weight:12Kg |
| Average power: 120W | Max power consumption: 220W |
| Electricity parameter | Brightness: 900 - 1500 nits |
| Brightness adjusted: 100 grade by software, or by Auto-optic induced |
| Color processing: 16bit |
| Display color: 280 trillion |
| Color temperature(k): 5000 — 9500 (choice by user) |
| Physical density: 27777 pixels/sqm |
| Whole display flatness: ≤ 1mm juncture |
| Best view distance: ≥ 5m |
| Best view angle: Horizontal ±80°, Vertical ±80° |
| Storage temperature: -35℃ ~ +85℃ Working temperature: -20℃ ~ +50℃ |
| Driving method: Constant driving current Scan: 1/12 |
| Refresh frequency: ≥ 1200Hz |
| Frame rate: ≥ 60Hz |
| Humidity(RH): ≤ 90~95% |
| Protection grade: IP64 |
| Working Voltage: DC 5V |
| Power supply: AC 110 / 220V, 50/60Hz |
| Average power consumption:300w/sqm |
| Max power consumption: 600w/sqm |
| MTBF: 10, 000 hours |
| Screen lifetime: 100, 000 hours |
| Control system | Signal interface: DVI |
| Communication distance: Internet cable: ≤120m Fiber cable: 1000m |
| Signal transfer mode: Pixels to pixels display synchronized |
>> seamless LED Video Wall
1. Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.
2.Thin cabinet:the thickness isonly10 CM, the space of the screen is small , and the entire screen will be more beautiful.
3.Flat screen: smooth surface error is under 0.2cm, it can remove the mosaic phenomenon .effectively. The effect of the display will be more clear and exquisite.
4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful.
5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.
